SINGLE DRY AGITATOR SEALS

Type RT-D80

  • Balance Pusher Seals.
  • Dry Run Seals are excellent in High Speed Seals for Operation in Vacuum Conditions.
  • Without Bearing OR with Integral Bearing.
  • Multiple Spring externally Mounted Seal with ‘O’ Ring as Secondary Sealing member.
  • Various Elastomers can be offered for various media application

Description

Dry Running Agitator Seals are outside-mounted, balanced single seal with self-lubricating seal faces. Neither external cooling, lubrication equipment nor a supply system is required. The design and material selection meet the needs of the pharmaceutical and chemical processing industries. The seals are excellent for low-duty mixing applications and operation in vacuum conditions. The seal can be supplied in component form consisting of spring-loaded face, driver retainer and mating ring, or pre-assembled on a flange.

We also manufacture and supply Single Agitator Seals, Double Agitator Seals and Glass Lined Reactor Mechanical Seals as being top most mechanical seal manufacturers in Mumbai as well as known as one of the most precise mechanical seal manufacturing companies in India.

FAQ

  • It seals the rotating shaft of agitators, mixers and reactors.
  • It is designed for applications where the seal operates without a liquid lubrication or flush system.
  • Suitable for processes where dry-running capability is required.
  • When the process does not allow or require a seal flushing or lubrication system.
  • It can be suitable for certain dry powders, solids and low-moisture processes.
  • The seal must be selected according to the actual application and operating conditions.
  • Check shaft diameter, agitator RPM, pressure and temperature.
  • Consider the process material and whether it contains abrasive particles.
  • Seal chamber dimensions and existing seal specifications are also important.
  • Clean and inspect the shaft and seal chamber before installation.
  • Install the seal according to the specified shaft and setting dimensions.
  • Ensure proper shaft alignment and handle the sealing faces carefully.
  • Check the seal after installation before starting the agitator.
  • Yes, replacement seals can be supplied according to your existing seal or agitator.
  • Share the shaft size, old seal dimensions, model number, photo or drawing.
  • The replacement can be matched according to RPM, pressure, temperature and process conditions.

Shaft Dia : 25mm to 150mm

Pressure : Full Vacuum to 6 bar

Temperature : -30°Cto150°C

Speed : 400 RPM

Seal Ring Faces    : Carbon and SiC

Seat Faces             : SiC and TC

Elastomer             : Viton, TTV, FEP and FFKM

MOC                     : SS 316 – CHANGE OF MOC ON REQUEST
