HOT OIL ROTARY JOINTS

RT-500-Series

  • Single and Dual Flow provision
  • Radial and axial housing connection
  • Self supported rotary joint
  • Easy and quick replacement of seals
  • Reliable usage with poor water quality
  • Stainless steel internal parts
  • Consult factory for special applications
  • LH & RH – UNF Threads
  • LH & RH Metric Threads on the Rotor
  • BSP & NPT Threads on B-Port

Description

The Type RT-600 Series is hot oil rotary joint which is easily replaceable, repairable, serviceable of sealing components on machine system i.e. No need to disassemble the joint from the system. Just remove bolts on the end cap and separate end cap with hoses. Remove old rotary seal and floating seal group and replace them with new ones. Having faster maintenance operation and possibility to quickly adapt the joint to fluids requiring different sealing materials. This product is particularly used in rubber, plastic and steel industries.

We also manufacture and supply Water Rotary Joint, Steam Rotary Joint and High Temperature Rotary Joint as being topmost Rotary Joints manufacturers in Mumbai as well as known as one of the most precise rotary Joints manufacturing companies in India.

FAQ

  • It transfers hot oil or thermal fluid between stationary piping and rotating equipment.
  • Commonly used in calender rolls, heating rolls, dryers and industrial processing machines.
  • It maintains continuous heat transfer while the equipment rotates.
  • Check oil temperature, pressure, flow rate and RPM.
  • Also confirm the shaft size, thread/connection and mounting arrangement.
  • For correct selection, provide your machine or existing rotary joint details.
  • The temperature capacity depends on the rotary joint design, sealing system and thermal oil used.
  • High-temperature applications require seals and materials specifically suitable for hot oil service.
  • Always select a joint according to the actual operating temperature.
  • Match the joint with the specified shaft and pipe connections.
  • Connect the hot oil inlet and outlet correctly.
  • Keep the joint properly aligned and avoid external pipe loads.
  • Check for leakage after installation and before full-speed operation.
  • Yes, replacement rotary joints can be supplied based on the existing unit.
  • Share the brand, model number, dimensions, photo or drawing.
  • We can evaluate the replacement according to temperature, pressure, RPM and fitting requirements.

Size

  •  1/4″ (DN08) – 4″ (DN100)

Parameter

  • Max. Hot Oil Pressure   : 7 bar
  • Max. Temperature         : 120ºC
  • Max. Speed                      :  3,500 RPM
  • Do not work with max. pressure at max. speed.

Seal Faces  : Cabon, SiC and TC

Elastomer   : Viton, Neoprene, EPDM, NBR and Buna-N

MOC            : SS 316, Brass, Carbon Steel.

Threaded rotor Mono Flow and Dual flow

Quick release rotor Mono Flow and Dual flow

Flanged rotor Mono Flow and Dual flow
